Features
Remote Monitoring and Control of Glove Box
Users can monitor the working conditions of the glove box from their computer or smartphone.
Data Encryption and Backup
When there is a data transmission error, interruption, corruption, or loss occurs because of network failure, users can restore and track historical data of the equipment through our system. You can configure the firewall to ensure data integrity and security.
Failure Alarm
If the equipment fails, the system will send a notification to the user and automatically start the failure protection routine.
Remote Diagnostics and Adjustments
Our engineers can access, debug, and restore the system remotely.
Online Help
Users can access online learning resources for the operation of the monitoring and control system. Users can also solve problems themselves using our Online Help site.
Free ustomer Service Online
We offer online communication tools (email, chat, video conference, etc.) with our service staff or engineers to solve issues if they arise.
Specifications
Main Chamber
Modular length: 1220mm/1500mm/1800mm/2440mm ( 48.0”/59.1”/70.9”/ 96.0”)
Modular depth: 750mm/1000mm/1200mm (29.5”/39.4”/47.2”)
Modular height: 900m( 35.4”)
Material: Stainless steel type 304, thickness 3mm (1/8”)
Sight Windows: Inclined, Safety Glass, thickness 8mm (1/3”)
Gloves Ports: POM (Polyoxymethylene), 220mm (8.7”) Diameter
Gloves: 8B1532
Dust Filter: HEPA 0.3μ, one gas inlet, one gas outlet
Shelving: Stainless Steel, two fixed shelves (adjustable shelves available)
Lighting: External LED lights, front mounted above sight glass.
Feedthroughs: One power feedthrough, 3 blind-flanges
Large Antechamber
Diameter: 360mm (14.2”) or 400mm (15.7”), Length 600mm (23.6”)
With Sliding tray
Spindle lock door, Vertical operation with lifting mechanism
Automatic door system, both inside door and outside door are inter-locked.
Small Antechamber
Diameter 150 mm (5.9”) or 100mm (3.9”), Length 300mm(11.8”)
Hinged door
Manual operation via hand valve
Purifier
Removal of H2O and O2 to Less than 1 ppm moisture and oxygen
Absorber Unit: 5kg Copper catalyst,5kg Molecular sieve
Capacity to remove oxygen, 60L , moisture 2000g.
Encapsulated Blower: 90m3/h
Regeneration: PLC control all process including heating, introducing mix gas (working gas mixed with Hydrogen 5-10%), etc.
System Control
PLC and HMI: Siemens S7
Based on the Internet of Things concept to realize remote Operation and Diagnose
Vacuum Pump
8m3/h Rotary vane pump with oil mist filter and gas ballast
Options&Accessories
Accessories Options
Moisture Sensor
Oxygen Sensor
Solvent Absorber
Heated Antechamber
Refrigerator
Cold Well
Microscope Unit
Ionizer without fan
Various Feedthroughs
Other Options
Customized box sizes
Integrating customer’s instruments into the glovebox, like evaporator, ALD System and Spin Coater etc.
Polycarbonate Window(s)
Quick Release Window(s)
Antechamber with interlocking door
Small chamber with sliding tray
Antechamber purging only without vacuum
Antechamber refilling from Gas cylinder instead of box
Rectangular Antechamber
Flexible shelves – adjustable up & down – adjustable back & forth
12m3/h Rotary pump
Dry scroll pump
Prompt service
Advantages
Remote Control and Diagnose
Based on the Internet of Things concept to realize remote operation and diagnose
High Capacity Purifier
Rapid removal of H2O and O2 to less than 1ppm
Long intervals between regeneration cycles.
PLC Control and Color Touchscreen HMI
Automatic Purge; Circulation; Regeneration; Pressure control; User Friendly Interface.
Long Life Moisture and Oxygen Analyzers
P2O5 Moisture Sensor: Corrosion resistant, Renewable by acid-cleaning if the probe is contaminated by HF or other corrosive environmental exposure.
ZrO2 Oxygen Sensor: Solid sensor, long life, can be exposed to air without consumption.
Customize a glove box specially for your application
Our engineering team can help to turn your idea into a solution.
Stainless Steel gas pipes and connectors
All the gloveboxes has been upgrade to stainless steel pipes and connectors with much higher corrosive-proof for highly corrosive environment.
